Internet Router¶
DHCP¶
Static DHCP:¶
| MAC | IP | NAME |
|---|---|---|
c8:d7:78:01:a8:20 |
192.168.1.131 | PIATAS |
b8:be:f4:db:c2:8d |
192.168.1.64 | DEVOLO |
d8:3a:dd:e1:d7:40 |
192.168.1.107 | PISRV2 LAN/PI5 |
d8:3a:dd:e1:d7:41 |
192.168.1.106 | PISRV2 WIFI/PI5 |
04:7c:16:7c:ac:19 |
192.168.1.190 | ICARUS |
2c:cf:67:13:fd:a6 |
192.168.1.108 | PISRV3 WIFI/PI5 |
2c:cf:67:13:fd:a3 |
192.168.1.109 | PISRV3 LAN/PI5 |
DC:A6:32:36:79:F5 |
192.168.1.145 | PIEDGE LAN/PI4 |
DC:A6:32:36:79:F7 |
192.168.1.146 | PIEDGE WIFI/PI4 |
DHCP Server Settings¶
IPv4 Port Mapping¶
| Mapping | Internal Host | Device | Protocol | External Port | Internal Port | Likely Service / Note |
|---|---|---|---|---|---|---|
| PISRV2-LAN | 192.168.1.107 |
pisrv2 |
TCP/UDP | 11022 |
22 |
SSH |
| PISRV2-LAN | 192.168.1.107 |
pisrv2 |
TCP/UDP | 11900 |
9000 |
Portainer / web admin |
| PISRV2-LAN | 192.168.1.107 |
pisrv2 |
TCP/UDP | 11010 |
10000 |
Web/admin service |
| PISRV2-LAN | 192.168.1.107 |
pisrv2 |
TCP/UDP | 11080 |
80 |
HTTP |
| PISRV2-LAN | 192.168.1.107 |
pisrv2 |
TCP/UDP | 11443 |
443 |
HTTPS |
| PISRV2-LAN | 192.168.1.107 |
pisrv2 |
TCP/UDP | 11081 |
81 |
Alternate HTTP/web service |
| PISRV2-WLAN | 192.168.1.106 |
pisrv2 |
TCP/UDP | 10022 |
22 |
SSH |
| PISRV2-WLAN | 192.168.1.106 |
pisrv2 |
TCP/UDP | 10010 |
10000 |
Web/admin service |
| PISRV3-LAN | 192.168.1.109 |
pisrv3 |
TCP/UDP | 13022 |
22 |
SSH |
| PIEDGE-LAN | 192.168.1.145 |
piedge |
TCP/UDP | 12022 |
22 |
SSH |
| PIEDGE-LAN | 192.168.1.145 |
piedge |
TCP/UDP | 12010 |
10000 |
Web/admin service |
| PIEDGE-LAN | 192.168.1.145 |
piedge |
TCP/UDP | 12080 |
80 |
HTTP |
| PIEDGE-LAN | 192.168.1.145 |
piedge |
TCP/UDP | 12443 |
443 |
HTTPS |
| PIEDGE-LAN | 192.168.1.145 |
piedge |
TCP/UDP | 80 |
80 |
Public HTTP |
| PIEDGE-LAN | 192.168.1.145 |
piedge |
TCP/UDP | 443 |
443 |
Public HTTPS |
| KANONIDIS | 192.168.1.29 |
kanonidis |
TCP/UDP | 14080 |
80 |
HTTP |
